Blog Detail
Bottom side adhere striped slags
Reason:Focus point too high;Gas pressure too low
Solutions:Reduce focus point;Improve gas pressure
The bottom section appears white
Reason:Focus point too high;Nozzle position height too low;Gas pressure too high
Solutions:Reduce focus point;Improve nozzle height;Reduce gas pressure
The bottom appear yellow
Reason:Focus point too high
Solutions:Reduce focus point
The bottom adhere drop-shaped tiny slag
Reason:Cutting speed too fast;Focus point too low
Solutions:Reduce cutting speed;Improve focus point
Corner adhere slags
Reason:Focus point too high
Solutions:Reduce focus point
Cutting gap increase
Reason:Protective lens dirtied
Solutions:Clean/replace protective lens
Cutting surface appears yellow
Reason:Gas impure;Gas tube mixed with air or Oxygen
Solutions:Checking Nitrogen and purity,required 99.99%;Checking gas tube;Checking delay
